High-voltage switchgear is an essential component in electrical power systems, as it helps control the flow and distribution of electricity. Industrial high-voltage switchgear, in particular, is designed for use in large-scale operations and industrial applications, where high-voltage electricity is used to power machinery, equipment, and processes. This article overviews industrial high-voltage switchgear, including its functions, types, and applications.

What is Industrial High Voltage Switchgear?

Industrial high-voltage switchgear is a collection of electrical equipment that controls and protects electrical power systems operating at voltages above 1 kV. It includes components such as circuit breakers, disconnectors, and transformers, which are used to regulate and distribute electrical power within an industrial setting. Industrial high-voltage switchgear is typically designed for indoor use and can be installed in various industrial settings, including power plants, refineries, mining facilities, and manufacturing plants.

High Voltage Switchgear


Learn more about our products with our experts

Functions of Industrial High Voltage Switchgear

The primary functions of industrial high-voltage switchgear are to control, isolate, and protect electrical power systems. Some of the specific functions of industrial high-voltage switchgear include:

  • Circuit Breaking: Industrial high-voltage switchgear is equipped with circuit breakers designed to interrupt the flow of electricity when there is a fault in the system, such as an overload or short circuit. This helps prevent damage to equipment and ensures the safety of personnel working in the facility.
  • Load Management: Industrial high-voltage switchgear is used to manage electrical power distribution within an industrial setting. It allows for the smooth and efficient transfer of electrical power from the source to the load, ensuring that the load is supplied with the necessary power without causing damage to the system.
  • System Protection: Industrial high-voltage switchgear protects the electrical power system from overvoltage, undervoltage, and other electrical faults. It also protects against electrical surges, lightning strikes, and other external factors that can damage the system.

Types of Industrial High Voltage Switchgear

Industrial high-voltage switchgear can be classified into two main types based on the type of insulation used:

  • Air-insulated Switchgear: Air-insulated Switchgear (AIS) uses air as the primary insulation medium to isolate and control the electrical power system. AIS is typically used for lower voltage applications and is known for its simple design, low cost, and ease of maintenance.
  • Gas-insulated Switchgear: Gas-insulated Switchgear (GIS) uses sulfur hexafluoride (SF6) gas as the primary insulation medium. GIS is designed for high-voltage applications and is known for its compact design, high reliability, and superior performance.
